Highlights:
- High-speed Wired Connection
- Plug and Play
- Compact Design
Features:
Auto-sensing 10/100 ports
The DES-1008A uses auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to Ethernet and Fast Ethernet devices to create an integrated network. These ports detect the network speed and auto-negotiate between 10BASE-T and 100BASE-TX, as well as between full and half-duplex, allowing you to get the maximum speed possible for each device connected to your network.
Auto MDI/MDIX CrossOver
All ports support automatic MDI/MDIX crossover, eliminating the need for crossover cables or uplink ports. Each port can be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables.
Flow Control for Secure Transmission
802.3x flow control on each port minimizes dropped packets when the port's receiving buffer is full. This gives you a more reliable connection for all of your connected devices.
Specifications:
| Device Interfaces | Eight 10/100 Fast Ethernet LAN ports | |
| Advanced Features | Green Ethernet 1.6 Gbps switching fabric Auto MDI/MDIX crossover for all ports Secure store-and-forward switching scheme Compliance with IEEE802.3az EEE power saving Full/half-duplex for Ethernet/Fast Ethernet speeds IEEE 802.3x Flow Control Plug-and-play installation RoHS compliant Supports 2048-byte Jumbo Frames | |
| Protocol | CSMA/CD | |
| Data Transfer Rates | Ethernet: 10 Mbps (half duplex) 20 Mbps (full duplex) Fast Ethernet: 100 Mbps (half duplex) 200 Mbps (full duplex) | |
| Transmission Method | Store-and-forward | |
| MAC Address Table | 2K | |
| MAC Address Learning | Automatic Update | |
| Packet Filtering/Forwarding Rates | Ethernet: 14,880 pps per port Fast Ethernet: 148,800 pps per port | |
| RAM Buffer | 96 KB per device | |
| LED Indicators | Per port: Link/Activity Per device: Power | |
| Media Interface Exchange | Auto MDI/MDIX adjustment for all ports | |
| Dimensions | 141.5 x 78.5 x 23.8 mm (5.57 x 3.09 x 0.94 inches) | |
| Power | 5 V/0.55 A Power Adapter | |
| Heat Dissipation | Power On (Standby): AC input:2.0472 Btu/h Maximum: AC input:7.47228 Btu/h | |
| Power Consumption | Power On (Standby): DC input: 0.36 watts, AC input: 0.6 watts Maximum: DC input: 1.78 watts, AC input: 2.19 watts Link Up: EEE mode: DC input: 0.75 watts AC input: 1.1. watts | |
| Temperature | Operating: 0 to 40 °C (32 to 104 °F) Storage: -10 to 70 °C (14 to 158 °F) | |
| Humidity | Operating: 10% to 90% non-condensing Storage: 5% to 90% non-condensing | |
| MTBF | 2,137,319 hours | |
| Certifications | CE Class B FCC Class B cUL CB VCCI Class B |
Warranty:
3 Years
