Interface

USB 2.0

Dimensions ( W x D x H )

19.2*15.7*7.4mm

Antenna

Omni Directional

Wireless Standards

IEEE 802.11b/g/n/ax 2.4 GHz, IEEE 802.11a/n/ac/ax 5 GHz

Frequency

5GHz
2.4GHz

Signal Rate

5GHz
11ax: Up to 600Mbps(dynamic)
11ac: Up to 433Mbps(dynamic)
11n: Up to 150Mbps(dynamic)
11a: Up to 54Mbps(dynamic)
2.4GHz
11ax: Up to 287Mbps(dynamic)
11n: Up to 200Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)

Reception Sensitivity

5GHZ：
11a6M：-94dBm；
11ax HE80 MCS11：-59dBm；
11ax HE80 MCS0：-87dBm；

2GHZ：
11g6M：-95dBm；
11ax HE40 MCS11：-65dBm；
11ax HE40 MCS0：-93dBm；

Wireless Modes

Infrastructure Mode

Wireless Security

WEP, WPA/WPA2/WPA3, WPA-PSK/ WPA2-PSK

Modulation Technology

DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM,
256-QAM, 1024-QAM

Certification

CE, FCC, RoHS

Package Content

AX900 Nano Wi-Fi 6 Bluetooth 5.3 USB Adapter Archer TX10UB Nano
Quick Installation Guide

System Requirements

Windows 11/10

Environment

Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing
