Honeywell Voyager 1202g-2 Wireless Handheld Barcode Scanner

Product Code: BCS-HNW-1202G-2USB5

MYR1079.00

Color

Brand: Honeywell

  • Share

Get shipping estimates

Country
State
Shipping Method

The Voyager 1200g (wired) and 1202g (wireless) barcode scanners give you able-bodied performance and flexibility for a wide variety of hands-free and handheld scanning applications. Regardless of the model you choose, these Voyager scanners deliver aggressive scan performance on virtually all linear barcodes.

Decode poorly printed, smudged, faded and other difficult-to-read barcodes with ease.
Scan high-density barcodes, too, with resolution down to 3.5 mil. In most cases, that eliminates the need to purchase specialty scanners.
And take advantage of the Voyager scanner’s class-leading, hands-free presentation scanning. It maximizes throughput with updated object detection and automatic in-stand detection and configuration.

We designed these Voyager scanners to decrease your downtime and service costs too.
Single shock-mounted PCB delivers greater impact resistance.
Recessed button is protected by an integrated rubber co-mold that minimizes the impact of accidental drops.
Designed with a protected, scratch-resistant glass window and an IP42-rating.
The Voyager 1202g wireless model incorporates a Bluetooth® Class 2 radio. You’ll have unrestricted movement up to 10 m (33 ft) from the base, and up to 30 m (100 ft) with a clear line-of-sight between scanner and base.

And if you ever misplace a scanner, the Voyager’s paging system uses visual and auditory signals to help you find the missing device quickly.

Highlights:
  • Aggressive Scan Performance
  • Wired or Wireless
  • Enable Presentation Scanning
  • Superior Out-of-Box Experience
  • CodeGate™ Technology

Specifications:

MECHANICAL

Dimensions (LxWxH)
1202g Scanner: 180 mm x 66 mm x 92 mm (7.1 in x 2.6 in x 3.6 in)
1202g Base: 200 mm x 67 mm x 97 mm (7.9 in x 2.6 in x 3.8 in)

Weight
1202g Scanner: 180 g (6.3 oz) (includes battery)
1202g Base: 125 g (4.4 oz)

ELECTRICAL

OPERATING POWER
1202g Scanner: N/A
1202g Base:
  • 5 W (1 A @ 5 V with power supply); 2.5W (0.5 A @ 5 V with USB)
  • 0.625 W (0.125 A @ 5 V)

Standby Power
1202g Scanner: N/A
1202g Base: N/A

Battery
1202g Scanner: 1800 mAh Li-ion minimum
1202g Base: N/A

Expected Operation Time
1202g: 12 hours

Expected Charge Time
1202gi: 4. hours

Number of Scans
1202g: Up to 45,000 scans per charge

Host System Interfaces
1202g Scanner: N/A
1202g Base: USB, Keyboard Wedge, RS232, IBM 46xx (RS485)

BLUETOOTH
1452g Radio/Range: 2.4 to 2.5 GHz (ISM Band) Adaptive Frequency Hopping Bluetooth v2.1: Class 2: 10 m (33 ft) line of sight
1452g Radio/Range: Up to 3 Mbps



ENVIRONMENTAL

Operating Temperature
1202g Scanner: 5°C to 40°C (41°F to 104°F)
1202g Base:
  • Charging: 5°C to 40°C (41°F to 104°F)
  • Non-Charging 0°C to 50°C (32°F to 122°F)

Storage Temperature
1202g: -5°C to 35°C (23°F to 95°F)

Humidity
0 to 95% relative humidity, non-condensing

Drop
Designed to withstand 30 1.5 m (5 ft) drops to concrete

Environmental Sealing
IP42

Light Levels
0 to 70,000 lux (6,500 foot-candles)



SCAN PERFORMANCE

Scan Pattern
Area Image (640 x 480 pixel array)

Motion Tolerance
Up to 10 cm/s (4 in/s) for 13 mil UPC at optimal focus

Scan Angle
Horizontal 37.8°; Vertical 28.9°

Symbol Contrast
35% minimum reflectance difference

Pitch, Skew
±60°, ±70°

Decode Capability
Reads standard 1D and GS1 DataBar symbologies. (Note: Decode capabilities dependent on kit configuration)



Part Number: 1202G-2USB-5



Warranty:
3 year factory warranty (Note: battery warranty is 1 year)
