D-Link DGS-1210-20 16-Port Web Smart Gigabit Switch+4 SFP Port
Product Code: NWS-DL-DGS121020
MYR799.00
Color
Brand: D-Link
Get shipping estimates
| Country | ||
| State | ||
| Shipping Method | ||
|
|
||
Highlights:
- 16 x 10/100/1000BASE-T ports
- 4 x Gigabit RJ45/SFP Combo ports
- Advanced L2 switching and security features
- L2+ Static Routing
- Optional “standard mode” or “surveillance mode” management user interface
Features:
Powerful, yet Cost-Efficient
The D-Link DGS-1210 Series Smart Managed Switches are the latest generation of switches to provide increased Power over Ethernet (PoE) output, a range of physical interface types, multiple management interfaces, and advanced Layer 2 features. With all of these features combined, the DGS-1210 Series provides a cost-efficient and flexible solution for expanding any business network.
The DGS-1210 Series switches support 8, 24, or 48 10/100/1000BASE-T ports. Each switch also supports an additional 2 or 4 Gigabit SFP ports for optical connections using multimode or singlemode SFP transceivers.
Powerful, yet Cost-Efficient
Five of the nine models in the DGS-1210 series family support Power-over-Ethernet capabilities, simplifying deployments with IP cameras, VoIP phones, wireless access points, and other powered devices. These models include the DGS-1210-10P, DGS-1210-10MP, DGS-1210-28P, DGS-1210-28MP and DGS-1210-52MP. Using the switch’s management interface, an administrator can control various PoE functions, such as remotely rebooting cameras or access points, from anywhere on the network, including over the Internet.
They also support time-based PoE, which allows administrators to set a time window that determines when each port’s PoE power is turned on and off. All PoE models support the IEEE 802.3af and 802.3at standards, and each PoE power budget varies per model.
Automatic Configuration
The DGS-1210 Series supports Auto Voice VLAN and Surveillance Mode, which allow voice and video traffic to be automatically identified and handled differently to regular network traffic. Auto Voice VLAN detects Voice over IP (VoIP) traffic and automatically segments it from the rest of the network, increasing security and allowing Quality of Service (QoS) to be applied.
Surveillance Mode detects compatible ONVIF cameras and places them in a surveillance VLAN, allowing a single switch to be used for voice, video, and data, removing the need for dedicated hardware and reducing maintenance costs. Surveillance Mode also includes its own Web UI, making surveillance features easily accessible and simplifying management of your surveillance network.
Extensive Management and Layer 2 Features
The DGS-1210 Series comes equipped with a complete lineup of L2 features, including IGMP snooping, port mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). The IEEE 802.3x Flow Control function allows servers to directly connect to the switch for fast, reliable data transfers.
The Series also supports advanced features such as static routing, which allows for communication between different user groups in different VLAN segments in a network. The switch can directly handle inter VLAN routing using multiple interfaces, making the network run faster and more efficiently. And, because the switches can manage internal routing, the network router can be assigned to handle external traffic routing only.
Comprehensive Security Features to Protect Your Network
D-Link’s innovative Safeguard Engine protects switches against traffic flooding and virus attacks. 802.11X port-based authentication allows the network to be authenticated through external RADIUS servers. In addition, the Access Control List (ACL) feature enhances network security and helps to protect the internal IT network.
Specifications:
|
1000Base-T Interface |
• 16 |
|
|
Combo 1000Base-T/SFP |
• 4 |
|
|
Auto MDI/MDIX |
• Yes |
|
|
10/100/1000BASE-T ports |
• 16 |
|
|
Combo 10/100/1000BASE-T/SFP ports |
• 4 |
|
|
Switch Capacity |
• 40 Gbps |
|
|
Max. Packet Forwarding Rate |
• 29.8 Mpps |
|
|
Store & Forwarding |
• Yes |
|
|
Dimension |
• 280mm x 180 mm x 44mm |
|
|
Weight |
• 1.75 kg |
|
|
Operation Temperature |
• -5 - 50°C |
|
|
Storage Temperature |
• -20-70°C |
|
|
Operation Humidity |
• 0% - 95% RH |
|
|
Storage Humidity |
• 0% ~ 95% RH |
|
|
Operating Altitude |
• 1500 meters |
|
|
Maximum Power Consumption |
• 13.08 W/100 V, 13.02 W/240 V |
|
|
Standby Power Consumption |
• 5.47 W/100V / 5.56 W/240V |
|
|
Maximum Heat Dissipation |
• 44.62 BTU/hr (100V), 44.41 BTU/hr (240V) |
|
|
Acoustic |
• 0 dB |
|
|
MTBF |
• 1,087,100 hours |
|
|
Power Input |
• 100-240 VAC |
|
|
CPU Speed |
• 500MHz |
|
|
DRAM Size |
• DDR3 128MB |
|
|
Flash Memory Size |
• 32MB |
|
|
Packet Buffer Size |
• 4.1MBits |
|
|
FAN |
• Fanless |
|
|
Comply with RoHS 6 |
• Yes |
|
|
Energy Efficiency Ethernet (EEE) |
• Yes |
|
|
Power Saving By Link Status |
• Yes |
|
|
Power Saving By Cable Length |
• Yes |
|
|
Power Saving By Port Shut-Off |
• Yes |
|
|
Power Saving By System Hibernation |
• Yes |
|
|
MAC Address Table Size |
• 8K |
|
|
802.3x Flow Control |
• Yes |
|
|
Head-of-line (HOL) Blocking Prevention |
• Yes |
|
|
802.1D Spanning Tree (STP) |
• Yes |
|
|
802.1w Rapid Spanning Tree (RSTP) |
• Yes |
|
|
802.1s Multiple Spanning Tree (MSTP) |
• Yes |
|
|
Root Restriction |
• Yes |
|
|
802.3ad Link Aggregation |
• Yes |
|
|
Max Port Per Link Aggregation Group |
• 8 |
|
|
Link Aggregation Group Per Device |
• 8 |
|
|
Port Mirroring |
• Yes |
|
|
Jumbo Frame |
• 10,000 Bytes |
|
|
Loopback Detection (LBD) |
• Yes |
|
|
IGMP Snooping |
• Yes |
|
|
Max IGMP Snooping Groups |
• 256 |
|
|
IGMP Snooping Fast Leave |
• Yes |
|
|
MLD Snooping |
• Yes |
|
|
MLD Snooping Groups |
• Yes |
|
|
MLD Snooping Fast Leave |
• Yes |
|
|
802.1Q VLAN |
• Yes |
|
|
VLAN Groups |
• Yes |
|
|
Port-based VLAN |
• Yes |
|
|
Voice VLAN |
• Yes |
|
|
Auto Surveillance VLAN |
• Yes |
|
|
Asymmetric VLAN |
• Yes |
|
|
IP Interface |
• Yes |
|
|
Max Number of IP Interface |
• 4 |
|
|
ARP Entries |
• Yes |
|
|
ARP |
• Yes |
|
|
IPv6 Neighbor Discovery (ND) |
• Yes |
|
|
ND Entries |
• 128 |
|
|
Default Route |
• Yes |
|
|
Static Route |
• Yes |
|
|
Number of Queue |
• Yes |
|
|
Class of Service (CoS) |
• Yes |
|
|
Strict Priority Queue (SPQ) |
• Yes |
|
|
Weighted Round Robin (WRR) |
• Yes |
|
|
Port-based Bandwidth Control |
• Yes |
|
|
Max Access Control List (ACL) Entries |
• Yes |
|
|
MAC Access List |
• Yes |
|
|
IP Access List |
• Yes |
|
|
IPv6 Access List |
• Yes |
|
|
SSH |
• Yes |
|
|
SSL |
• Yes (only support TLS 1.0) |
|
|
Port Security |
• Yes |
|
|
Broadcast/Multicast/Unicast Storm Control |
• Yes |
|
|
Traffic Segmentation |
• Yes |
|
|
Smart IP-MAC-Port Binding (Smart IMPB) |
• Yes |
|
|
D-Link Safeguard Engine |
• Yes |
|
|
DHCP Server Screening |
• Yes |
|
|
ARP Spoofing Prevention |
• Yes |
|
|
DoS Attack Prevention |
• Yes |
|
|
802.1X |
• Yes |
|
|
Port based 802.1X Authentication |
• Yes |
|
|
Authentication for Management Access |
• Yes |
|
|
RADIUS |
• Yes |
|
|
Trusted Host |
• Yes |
|
|
Cable Diagnostics |
• Yes |
|
|
Simple Network Time Protocol (SNTP) |
• Yes |
|
|
Web-based GUI |
• Yes |
|
|
Telnet Server |
• Yes |
|
|
SNMP |
• Yes |
|
|
SNMP Trap |
• Yes |
|
|
TFTP Client |
• Yes |
|
|
System Log |
• Yes |
|
|
RMONv1 |
• Yes |
|
|
LLDP |
• Yes |
|
|
LLDP-MED |
• Yes |
|
|
D-Link Discover Protocol (DDP) |
• Yes (v0.26) |
|
|
DHCP/BootP Client |
• Yes |
|
|
DHCP relay |
• Yes |
|
|
Dual Images |
• Yes |
|
|
Dual Configurations |
• Yes |
|
|
Debug Command |
• Yes |
|
|
Ping |
• Yes |
|
|
D-Link Network Assistant |
• Yes (Chrome edition) |
|
|
Smart Wizard |
• Yes |
Warranty:
Limited Lifetime
