D-Link DGS-1210-10P 8-Port Web Smart Gigabit POE Switch+2 Combo SFP
Product Code: NWS-DL-DGS121010P
MYR829.00
Color
Brand: D-Link
Get shipping estimates
Country | ||
State | ||
Shipping Method | ||
|
Product Code: NWS-DL-DGS121010P
MYR829.00
Brand: D-Link
Country | ||
State | ||
Shipping Method | ||
|
1000Base-T PoE Interface |
• 8 |
|
1000M SFP Interface |
• 2 |
|
Auto MDI/MDIX |
• Yes |
|
10/100/1000BASE-T PoE ports |
• 8 |
|
SFP ports |
• 2 |
|
Switch Capacity |
• 20 Gbps |
|
Max. Packet Forwarding Rate |
• 14.88 Mpps |
|
Store & Forwarding |
• Yes |
|
Weight |
• 0.95 kg |
|
Dimension |
• 280mm x 126 mm x 44mm |
|
Operation Temperature |
• -5 - 50°C |
|
Storage Temperature |
• -20-70°C |
|
Operation Humidity |
• 0% - 95% RH |
|
Storage Humidity |
• 0% ~ 95% RH |
|
Operating Altitude |
• 1500 meters |
|
Maximum Power Consumption |
• PoE on, 81.9 W/100 V, 80.6 W/240 V PoE off, 7.6 W/100 V, 7.5 W/240 V |
|
Standby Power Consumption |
• 2.5 W/100V / 2.5 W/240V |
|
Maximum Heat Dissipation |
• 279.59 BTU/hr (100 V), 275.04 BTU/hr (240 V) |
|
Acoustic |
• 0 dB |
|
MTBF |
• 729,258 hours |
|
Power Input |
• 100-240 VAC |
|
CPU Speed |
• 500MHz |
|
DRAM Size |
• DDR3 128MB |
|
Flash Memory Size |
• 32MB |
|
Packet Buffer Size |
• 4.1MBits |
|
FAN |
• Fanless |
|
Comply with RoHS 6 |
• Yes |
|
Energy Efficiency Ethernet (EEE) |
• Yes |
|
Power Saving By Link Status |
• Yes |
|
Power Saving By Cable Length |
• Yes |
|
Power Saving By Port Shut-Off |
• Yes |
|
Power Saving By System Hibernation |
• Yes |
|
Time-based PoE |
• Yes |
|
Maximum PoE Budget |
• 65Watts |
|
PoE Budget |
• 65 W |
|
MAC Address Table Size |
• 8K |
|
802.3x Flow Control |
• Yes |
|
Head-of-line (HOL) Blocking Prevention |
• Yes |
|
802.1D Spanning Tree (STP) |
• Yes |
|
802.1w Rapid Spanning Tree (RSTP) |
• Yes |
|
802.1s Multiple Spanning Tree (MSTP) |
• Yes |
|
Root Restriction |
• Yes |
|
802.3ad Link Aggregation |
• Yes |
|
Max Port Per Link Aggregation Group |
• 8 |
|
Link Aggregation Group Per Device |
• 8 |
|
Port Mirroring |
• Yes |
|
Jumbo Frame |
• 10,000 Bytes |
|
Loopback Detection (LBD) |
• Yes |
|
IGMP Snooping |
• Yes |
|
Max IGMP Snooping Groups |
• 256 |
|
IGMP Snooping Fast Leave |
• Yes |
|
MLD Snooping |
• Yes |
|
MLD Snooping Groups |
• Yes |
|
MLD Snooping Fast Leave |
• Yes |
|
802.1Q VLAN |
• Yes |
|
VLAN Groups |
• Yes |
|
Port-based VLAN |
• Yes |
|
Voice VLAN |
• Yes |
|
Auto Surveillance VLAN |
• Yes |
|
Asymmetric VLAN |
• Yes |
|
IP Interface |
• Yes |
|
Max Number of IP Interface |
• 4 |
|
ARP Entries |
• Yes |
|
ARP |
• Yes |
|
IPv6 Neighbor Discovery (ND) |
• Yes |
|
ND Entries |
• 128 |
|
Default Route |
• Yes |
|
Static Route |
• Yes |
|
Number of Queue |
• Yes |
|
Class of Service (CoS) |
• Yes |
|
Strict Priority Queue (SPQ) |
• Yes |
|
Weighted Round Robin (WRR) |
• Yes |
|
Port-based Bandwidth Control |
• Yes |
|
Max Access Control List (ACL) Entries |
• Yes |
|
MAC Access List |
• Yes |
|
IP Access List |
• Yes |
|
IPv6 Access List |
• Yes |
|
SSH |
• Yes |
|
SSL |
• Yes (only support TLS 1.0) |
|
Port Security |
• Yes |
|
Broadcast/Multicast/Unicast Storm Control |
• Yes |
|
Traffic Segmentation |
• Yes |
|
Smart IP-MAC-Port Binding (Smart IMPB) |
• Yes |
|
D-Link Safeguard Engine |
• Yes |
|
DHCP Server Screening |
• Yes |
|
ARP Spoofing Prevention |
• Yes |
|
DoS Attack Prevention |
• Yes |
|
802.1X |
• Yes |
|
Port based 802.1X Authentication |
• Yes |
|
Authentication for Management Access |
• Yes |
|
RADIUS |
• Yes |
|
Trusted Host |
• Yes |
|
Cable Diagnostics |
• Yes |
|
Simple Network Time Protocol (SNTP) |
• Yes |
|
Web-based GUI |
• Yes |
|
Telnet Server |
• Yes |
|
SNMP |
• Yes |
|
SNMP Trap |
• Yes |
|
TFTP Client |
• Yes |
|
System Log |
• Yes |
|
RMONv1 |
• Yes |
|
LLDP |
• Yes |
|
LLDP-MED |
• Yes |
|
D-Link Discover Protocol (DDP) |
• Yes (v0.26) |
|
DHCP/BootP Client |
• Yes |
|
DHCP relay |
• Yes |
|
Dual Images |
• Yes |
|
Dual Configurations |
• Yes |
|
Debug Command |
• Yes |
|
Ping |
• Yes |
|
D-Link Network Assistant |
• Yes (Chrome edition) |
|
Smart Wizard |
• Yes |
Warranty:
Limited LifetimeMYR1699.00
