Device Interfaces

• 5 x Gigabit Ethernet LAN ports, 1 x power connector

Standards

• IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x Flow Control
• IEEE 802.3az Energy-Efficient Ethernet (EEE)

Advanced Features

• Green Ethernet
• 10 Gbps switching fabric
• Auto MDI/MDIX crossover for all ports
• Secure store-and-forward switching scheme
• Full/half-duplex for Ethernet/Fast Ethernet speeds
• IEEE 802.3x Flow Control
• Supports 9KB Jumbo Frame
• Supports IEEE 802.1p QoS

Data Transfer Rates

• Ethernet:
• 10 Mbps (half duplex)
• 20 Mbps (full duplex)
Fast Ethernet:
• 100 Mbps (half duplex)
• 200 Mbps (full duplex)
Gigabit Ethernet:
• 2000 Mbps (full duplex)

Transmission Method

• Store-and-forward

MAC Address Table

• 2K

MAC Address Learning

• Automatic Update

Packet Buffer

• 128 KB

LED Indicators

• Per port: Link/Activity
• Per device: Power

Media Interface Exchange

• Auto MDI/MDIX for all ports

Dimensions

• 94 x 75 x 22.45 mm

Weight

• 75 g

Power

• 5 V/1 A Power Adapter

MTBF

• 1,479,725 hours
