Presentation High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions. Lead time Usually in Stock Main Input Voltage 230 V Other Input Voltage 220 V
240 VMain Output Voltage 230 V Other Output Voltage 220 V
240 Vrated power in W 1800 W Rated power in VA 2000 VA Input Connection Type IEC 60320 C14 output connection type 4 IEC 60320 C13 Cable length 1.5 m Number of cables 1 Provided equipment 1 IEC 60320 C13 to Schuko power cable
1 IEC 60320 C13 to C14 power cable
1 USB cable
1 RS-232 configuration cable
user manualRun Time View Runtime Graph Efficiency View Efficiency Graph Battery type Lead-acid battery Battery voltage 48 V Number of battery filled slots Number of battery free slots Battery recharge time 4 h Battery life 3…5 year(s) Battery charger power 70 W rated Max runtime 3 min Number of power module filled slots Number of power module free slots Redundant No Colour Black (RAL 7010) Height 23.8 cm Width 14.5 cm Depth 40 cm Net weight 17.0 kg Mounting location Front Mounting preference No preference Mounting mode Not rack-mountable USB compatible Yes Mounting position Vertical Input voltage limits 110...285 V half load
180...285 V full loadNetwork frequency 40...70 Hz auto sensing Maximum configurable power in VA 2000 VA Maximum configurable power in W 1800 W Output frequency 50/60 Hz +/- 3 Hz sync to mains Harmonic distortion 3 % UPS type Double conversion online Wave type Sine wave Efficiency 88 % (full load) Additional information Configurable for 220 : 230 or 240 nominal output voltage bypass type Internal bypass (automatic and manual) Crest factor 3 : 1 Product certifications CE
UKCA
TISIStandards EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018Ambient air temperature for operation 0…40 °C Relative humidity 0…95 % non-condensing Operating altitude 0...3000 m Ambient air temperature for storage -20…50 °C Storage Relative Humidity 0…95 % non-condensing Storage altitude 0…15000 m Acoustic level 50 dBA heat dissipation 759 Btu/h IP degree of protection IP20 Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm Free slots 1 control panel Multifunction LCD status and control console Surge energy rate 945 J Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 35.5 cm Package 1 Width 52.5 cm Package 1 Length 23.5 cm Package 1 Weight 18.9 kg Warranty 2 years repair or replace
Note: This item only can be shipped to West Malaysia. Kindly contact seller to ask for shipping fee to East Malaysia. Oversea country shipping not available.
