• Print Methods: Thermal transfer and direct thermal printing

• Construction: Metal frame and bi-fold metal media cover with enlarged clear viewing window

• Side-loading supplies path for simplified media and ribbon loading

• Thin film printhead with E3™ Element Energy™ Equalizer for superior print quality

• Communications: USB 2.0, RS-232 Serial, Gigabit Ethernet, Bluetooth® 4.0

• Brightly lit, 4.3 in. full-color touch display with clear navigation and immediate status visibility and support

Dimensions (closed)

ZT610: 19.88 in. L x 10.56 in. W x 15.58 in. H
505 mm L x 268.2 mm W x 395.68 mm H
ZT620: 19.88 in. L x 13.44 in. W x 15.58 in. H
505 mm L x 341.45 mm W x 395.68 mm H

Weight

ZT610: 50 lbs/22.7 kg
ZT620: 57.4 lbs/26 kg

Operating System

Link-OS

Resolution

203 dpi/8 dots per mm
300 dpi/12 dots per mm (optional)
600 dpi/24 dots per mm (optional for ZT610 only)

Memory

1 GB RAM memory
2 GB  on-board linear Flash memory

Maximum Print  Width

ZT610: 4.09 in./104 mm
ZT620: 6.6 in./168 mm

Maximum Print Speed

ZT610:  14 ips/356 mm per second
ZT620:  12 ips/305 mm per second

Media Sensors

Dual media sensors: transmissive and reflective

Maximum Continuous Print Length

ZT610:
203 dpi: 150 in./3810 mm
300 dpi: 100 in./2540 mm
600 dpi: 30 in./762 mm

ZT620:
203 dpi: 80 in./2032 mm
300 dpi: 80 in./2032 mm

Media Width

ZT610: 0.79 in./20 mm to 4.5 in./114 mm
ZT620: 2.0 in./51 mm to 7.1 in./180 mm

Maximum Media
Roll Size

8.0 in./203 mm O.D. on a 3 in./76 mm I.D. core

Thickness

0.0023 in./0.058 mm to 0.010 in./0.25 mm

Media Types

Continuous, die-cut, notch, black-mark

Standard Length

1476 ft./450 m

Width

ZT610: 0.79 in./20 mm to 4.33 in./110 mm
ZT620: 2.0 in./51 mm to 6.7 in./170 mm

Core

1.0 in./25.4 mm I.D.

Operating Temperatures

Thermal transfer: 40ºF to 104ºF/5ºC to 40ºC
Direct thermal: 32ºF to 104ºF/0ºC to 40ºC

Operating Humidity

 20% to 85% non-condensing

Storage/Transportation Temperature

-22°F to 140°F/-30°C to 60°C

Storage Humidity

20% to 85% non-condensing

Electrical

Auto-detectable (PFC Compliant) 90-265 VAC, 47-63Hz, rated at 250 Watts
ENERGY STAR qualified

Agency Approvals

IEC 60950, EN 55022 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3
cTUVus, CE Marking, FCC-B, ICES-003, VCCI, C-Tick, NOM, S-Mark (Arg), CCC, CU, BSMI, KCC, SABS, IN-Metro

ZBI 2.0™–Optional powerful programming language that lets printers run stand-alone applications, connect to peripherals and much more.
ZPL and ZPL II™–Zebra Programming Language provides sophisticated label formatting and printer control, and is compatible with all Zebra printers.
XML-enabled Printing–allows XML communications for barcode label printing.

Linear Barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar, Planet Code
2D Barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39, MicroPDF, RSS-14 (and composite), Aztec
