• Print methods: Thermal Transfer or Direct Thermal
• ZPL and EPL programming languages
• Single LED status indicator
• Single button for feed/pause
• USB connectivity
• OpenACCESS™ for easy media loading
• Dual-wall frame construction
• ENERGY STAR qualified
• ZebraDesigner Essentials–easy label design tool free at
www.zebra.com/zebradesigner

Dimension

Thermal Transfer:
10.5 in. L x 7.75 in. W x 7.5 in. H
267 mm L x 197 mm W x 191 mm H
Direct Thermal:
8.6 in. L x 6.9 in. W x 5.9 in. H
220 mm L x 176 mm W x 151 mm H

Weight

Thermal Transfer:
3.7 lbs./1.7 kg
Direct Thermal:
2.5 lbs./1.1 kg

Resolution

203 dpi/8 dots per mm

Memory

128 MB Flash; 128 MB SDRAM

Maximum Print Width

4.09 in./104 mm

Print Speed

4 in./102 mm per second

Media Sensors

Movable black mark sensor, limited range from center to left side
Fixed off-center gap sensor

Firmware

ZPL II; EPL 2; XML

Maximum Label Length

39.0 in./991 mm

Media Width

1.00 in./25.4 mm to 4.4 in./112 mm

Media Roll Size

5.00 in./127 mm outer diameter
Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1 mm) using optional adapters

Thickness

0.003 in. (0.08 mm) min.; 0.0075 in. (.1905 mm) max. (tear-off mode only)

Media Types

Roll-fed or fan-fold, die cut or continuous with or without black mark, tag stock, continuous receipt paper, and wristbands

Ribbon Outside Diameter

1.34 in./34 mm (74 m)

Maximum Ribbon Length

244 ft. (74 m)

Ribbon Ratio

1:1 ribbon to media (74 m)

Ribbon Width

1.33 in./33.8 mm-4.3 in./109.2 mm

Ribbon Core I.D.

74 meter ribbon 0.5 in./12.7 mm

Operating Temp.

40° to 105° F/4.4° to 41° C

Storage Temp.

-40° to 140° F/-40° to 60° C

Operating Humidity

10% to 90% non-condensing

Storage Humidity

5% to 95% non-condensing

Electrical

Auto-detectable (PFC Compliant) 100-240VAC, 50-60Hz; ENERGY STAR qualified

Media Handling

Factory installed peeler

Real Time Clock

None

Bar Code Ratios

2:1 and 3:1

1D Bar Codes

Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code

2D Bar Codes

Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec

Fonts and Graphics

16 resident expandable ZPL II bitmap fonts
Two resident scalable ZPL fonts
Five resident expandable EPL2 fonts
Native open-type font support
Unicode compliant for multi-language, on demand thermal printing
50 MB user available non-volatile memory,  8 MB user available SDRAM

For industry-leading quality, service and thermal printing expertise, choose Zebra Certified Supplies to ensure consistent, optimized performance for your Zebra printer.

IEC 60950-1, EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, FCC Class B, ICES-003, FCC 15.209; 15.247(d), IC RSS 247, EN 300 328, EN 301 893, EN 62311, cTUVus
CE Marking, VCCI, C-Tick, S-Mark, CCC, CU, BSMI, KCC, SABS, IN-Metro, BIS, NOM

Zebra OneCare™ maintenance plans provide peak performance and device uptime while protecting your critical operations and your printers with defined service levels. For more information go to www.zebra.com/zebraonecare

ZebraOneCare Essential

Comprehensive Coverage, including printheads, normal wear and accidental breakage
Priority access 8x5 live technical support and software updates
Three-day depot repair turnaround time plus free return ground shipping
Online Return Material Authorization (RMA) support

Note: Service availability may vary by region.

Link-OS® Basic printer operating system

This printer is supported by a core set of Print DNA Basic applications and capabilities.

Zebra Setup Utilities

Enhances out-of-the-box experience by enabling quick and easy printer configuration

ZebraDesigner
Essentials

Makes designing and printing industry-standard and compliant labels simple, including fixed or variable data

Emulations

On-printer apps allow Zebra printers to use legacy languages normally associated with other printer brands

For more information please visit www.zebra.com/printdna
