With the TM-T81II, businesses can now enjoy reputed reliability, economically. The ergonomic design of the printer allows for hassle-free paper reloading and features a cost efficient paper saving function.

Highlights:

• Thermal line printing
• 60 million lines MCBF (Mean Cycle between Failures)
• Auto-cutter life of 1.5 million cuts
• Printing speed of up to 150mm/s
• Paper saving function

Features:

Reputed Reliability
MCBF of 60 million lines and an auto-cutter life of 1.5 million cuts.

Hassle-free Design
Integrated power supply with easy paper-loading.

Paper Saving
Reduce paper margins, line spacing and barcode heights with Epson’s automatic paper reduction function.

Specifications:

Print Font:

Font: 9 × 17 / 12 × 24 Column Capacity: Paper width 80 mm: 48 / 64 Character Size (W x H): 0.88 (W) × 2.13 (H) / 1.25 (W) × 3 (H) Character Set: 95 Alphanumeric characters, 18 set International, 128 x 43 pages (including user-defined page)
Hanzi: Simplified Chinese: GB18030-2000: 28,553
Bar code: UPC-A, UPC-E, JAN13(EAN13), JAN8(EAN8), CODE39, ITF, CODABAR(NW-7), CODE93, CODE128
Two-dimensional code: PDF417, QRCode Characters Per Inch: 22.6 cpi / 16.9 cpi

Paper:

Roll Paper: 79.5 ± 0.5 (W) × Dia. 83.0
57.5 ± 0.5 (W) × Dia. 83.0 Roll Paper Near-end Sensor:Mounted

Overall Dimensions (D x W x H):

Overall Dimensions (D x W x H): 199 × 140 × 146 mm

Printing Method:

Printing Method: Thermal line printing

Standard Accessories:

Standard Accessories: Roll paper × 1 roll (for checking the initial movement of the printer)
CD-ROM (Drivers, Tool software, User’s manual)*
Power switch cover
Interface cable

Dot Density:

Dot Density: 203 dpi × 203 dpi

Mass:

Mass: Approx. 1.7 kg

Interfaces:

Ethernet: Built-in Ethernet (P/N: C31CB10823),  USB: Built-in USB + Serial (P/N: C31CB10821)

EMI and Safety Standards:

Data Buffer: 4 KB or 45 bytes

Reliability:

MTBF: 360,000 hours MCBF: 60,000,000 lines Printer Mechanism Life: 15 million lines Auto Cutter Life: 1.5 million cuts

Printer Type:

Print Speed : Max 150 mm/s

Power:

Supply Voltage and Frequency: 100 - 240 V AC, 50 / 60 Hz Power Consumption: 1.0 A Power Supply: Internal D.K.D. Function: 2 Drives

Part Number:

C31CB10821 (Built-in USB + Serial)
C31CB10823 (Built-in Ethernet)

Warranty:

1 Year
